Cylinder Kit (STD) for John Deere AR78041

Cylinder Kit (STD) for John Deere AR78041

See if this fits your application
SKU: NRE53321
In Stock (99+)
Add to your cart
Condition: New Aftermarket
Cross-References: 105-28761, 13190/F66, 14010171, 151628, 226-1584, 2261584, 31-49, 3100490, 50517973, A-AR78041, ABRE53321, AR71592, AR78041, ARE53321, FP-AR78041, FP-RE53321, FPAR78041, FPRE53321, G664, HCRNRE53321, HRE-53321, HRE53321, JD31-RE53321-MX, JD31-RE53321-PR1, JD31-RE53321-PR3, JD31-RE53321-PR6, NAR78041, NRE53321, P151628, PK475, PK476, PK477, RE53321, SA324, SAT475, SK444, SL2516, TAR78041, TRE53321
The RF Engine Advantage
Family Operated Since 1975

Original Equipment Quality

Parts that meet or exceed OEM specifications. Guaranteed performance you can trust. Reliability built into every component.

100+ Years of Expertise

A century of collective diesel knowledge and 10+ acres of engines and engine parts, we are more than just an online reseller or call center. We know heavy-duty diesel.

Here for the Long Haul

Same location and same phone number for the last 50 years. Same commitment to getting you the right parts at the right price.

New, Reman, & Used

RF Engine offers an expansive offering of new aftermarket, remanufactured, and used engines and engine parts all under one roof.

Details

John Deere 164 Diesel
John Deere 1520, 1530 Diesel
John Deere Industrial 302, 302A, 310, 350C
John Deere 2040

John Deere 219 Diesel

John Deere 2030, 2440, 2520 Diesel
John Deere Industrial 310A, 310B, 401A, 401B, 401C, 401D, 410, 410B, 440A, 440B, 450A, 450B, 480A, 480B, 480C

John Deere 219T Diesel

John Deere Industrial 450C, 450D, 455D

John Deere 329 Diesel

John Deere Industrial 444, 444C, 540A, 544A, 570A
John Deere 2840, 4030 Diesel

John Deere 329T Diesel

John Deere Industrial 710B


Piston Specifications
Material:    Aluminum
Bore Diameter:     4.020IN
Piston Length:     4.38IN
Piston Pin Diameter:     1.375IN
Piston Pin Part Number (Cram):     2231901
Compression Distance:     2.609IN
Compression Ring Groove 1:     1-1/8IN
Oil Ring Groove Width 1:     13/64IN


Sleeve Specifications
Bore Diameter:     4.020IN
Flange Outer Diameter:     4.920IN
Flange Width:     0.238IN
Sleeve O.D. at Pilot:     4.685IN
Sleeve O.D. at Barrel:     4.637IN
Sleeve Outer Diameter at Seal:     4.371IN
Length:     7.72IN
Firewall:     0.0285
Sleeve Type:    Wet
OEM Part Number Cross Reference(s): AR78041, RE53321, AR71592

Our aftermarket replacement parts are built to OEM-equivalent standards. They have been produced to meet or exceed original equipment specifications for material quality, dimensional tolerance, and field durability — the same rigors the factory part is designed to handle. The result is a component that installs like factory, performs like factory, and delivers long service life without the dealer price tag.

Fitment Guide

Backhoe Loaders (10)
John Deere 300B
John Deere 302A
John Deere 310A
John Deere 310B
John Deere 401C
John Deere 401D
John Deere 410
John Deere 410B
John Deere 710B
John Deere JD310
Combines (4)
John Deere 3300
John Deere 4400
John Deere 4420
John Deere 6600
Cotton Pickers (2)
John Deere 499
John Deere 9900
Cotton Strippers (2)
John Deere 482
John Deere 484
Crawlers (5)
John Deere 350C
John Deere 450C
John Deere 450D
John Deere 455D
John Deere JD450B
Forklifts (2)
John Deere 480C
John Deere JD480B
Graders (1)
John Deere 570A
Knuckleboom Loaders (3)
John Deere 7610
John Deere 7620
John Deere 7630
Log Skidders (1)
John Deere JD540A
Power Units (5)
John Deere 3164D
John Deere 329DH01
John Deere 329DH02
John Deere 329DN03
John Deere 6329D
Sprayers (1)
John Deere 6000
Tractors (16)
John Deere 1020
John Deere 1030
John Deere 1120
John Deere 1130
John Deere 1530
John Deere 1830
John Deere 2030
John Deere 2040
John Deere 2120
John Deere 2440
John Deere 2840
John Deere 3030
John Deere 3130
John Deere 4030
John Deere 830
John Deere 930
Wheel Loaders (5)
John Deere 444C
John Deere 444CH
John Deere 444D
John Deere JD444
John Deere JD544A
Wheel Tractors (3)
John Deere 301A
John Deere 302
John Deere 401B
Windrowers (3)
John Deere 2270
John Deere 2280
John Deere 2420
Engines (3)
John Deere 6329 | Naturally Aspirated or Turbocharged, Late SN, 1.375" Piston Pin, Has o-ring grooves in block
6-cyl • Diesel
John Deere 4219D, 4219T | Naturally Aspirated or Turbocharged, Late SN, 1.375" Piston Pin, Has o-ring grooves in block
4-cyl • Diesel
John Deere 3164 | Late SN, 1.375" Piston Pin, Has o-ring grooves in block
3-cyl • Diesel
While every effort has been made to ensure the accuracy of the fitment information listed above, it is ultimately the responsibility of the installing mechanic to perform a side-by-side comparison of the replacement part with the original to verify proper fit before installation. RF Engine is not liable for labor or consequential damages resulting from incorrect application.
